Sensor installation After the sensor wiring and sealing is completed, evenly apply 2-3mm of the accompanying coupling agent on the transmitter surface of the sensor, and then install the sensor on the treated pipeline surface according to the installation distance, and use the clamp to fix it. The "Z" method is recommended for pipe diameter greater than DN100 Installation distance The installation distance between the two sensors is determined by the distance between the innermost edges of the two sensors (see the following figure). The calculation method of the installation distance is to enter the correct parameters in the menu, view the number displayed in the window M25, and install the sensor according to this data. The pipe diameter is less than or equal to DN100. The "V" method is recommended for installation Installation distance The installation distance between the two sensors is determined by the distance between the innermost edges of t…
