64FeNi is an iron-nickel alloy containing 35-36% nickel and characterized by an extremely low coefficient of thermal expansion (excellent for applications requiring no dimensional changes with temperature variations.) Invar is strong, tough, ductile and possesses a useful degree of corrosion resistance. It is magnetic in the temperature range up to 400 oF.
Applications:
Precision instruments, measuring tapes, weights, etc.
GENERAL PROPERTIES
Specific Gravity:
8.08
Melting Point:
2600 oF
Density:
0.292 lb/in3
Electrical Resistance:
494 ohms/mil/ft
Specific Heat:
0.123 BTU/lb/oF
Thermal Conductivity:
72.6 BTU/ft2/in/oF/hr
