Energy Saving Jet Mill

LNSE Energy Saving Jet Mill Working principal: Energy-saving Jet Mill is a newly developed grinding equipment based on the fluid energy conversion character in adiabatic flow process. It makes most of fluid pressure and internal energy to grind material with a high efficient and saves 30% energy than other ordinary Jet milling equipment. -How did we achieve 30% energy saving? -In order to avoid excessive exhaust temperature from affecting the performance of cylinder lubricating oil and obtain higher pressure, the conventional air compressor for jet mill uses intercooling for multi-stage compression. The more stages, the lower the energy utilization rate, such as the first stage compression energy. The utilization rate is 78% (the first-stage compression pressure is 0.3-0.35MPa), and the second-stage compression is 58% (the second-stage compression pressure is 0.7-0.9MPa).  The energy-saving jet mill can use the high-temperature compressed gas discharged from th…
