QPA1000 Quintuplex Plunger Pump Fracturing Pumps

Quintuplex Plunger Pump QWS1000 Well Service Pump QWS1000 Pump is directly connected with the plunger and the cross head which reducing the pump's length so that it is easy to layout on the device. QWS1000 pump is a quintuplex plunger pump with offset design similar to 600S Triplex Plunger Pump in configuration, yet with higher horsepower and larger displacement under the same pressure. The compact structure enables twin-pump layout on one unit, making it the top choice of Cementing Equipmentand fracturing Equipment. （1） Power end Technical parameters Power Braking (Max) 1,000HP (746KW) Connecting rod Load (Max) 100,000 lbf (445KN)  Stoke 6" (152.4mm)  Speed rations 4.61:1 L×W×H mm 74.6×50.8×31.1 in. (1,895×1,292×792mm) Weight 7,231lbs (3,280Kg)   (2)  Fluid end Item Model Specification Monthly output/ Set L×W×H mm Fluid end 1000 3",3.5" 40 11…
