1.Product feature
Product feature
Current ripple: ±5%
Protection: open circuit / short circuit / overload / class II
Start time:≤0.5S(230VAC,full load)
Ambient Temp: -25~50℃
Storage Temp:-25~85℃
5 years warranty
Certificates: TUV/CE/SAA/CCC
Application: Wall lamp,Downlight,spotlight
Size: 33.9*22.8*17mm (L*W*H)
2.Product parameter list
3.Connected quantities of different current Breaker
4.Lifetime curve
5.Wiring Diagram
6.Packing information
7.Wiring instructions
• All connections must be kept as short as possible to ensure good EMI behaviour
• Mains leads should be kept apart from LED Driver and other leads (ideally 5 – 10 cm distance)
• Advice the maximum length of output wires is 3 m
• Secondary switching is not permitted(Except for constant voltage)
• Incorrect wiring can damage LED modules.
• The wiring must be protected against short circuits to earth (sharp edged metals parts, metal cable clips, louver,
e…
