2.54mm pitch pin header circuit board connector

2.54mm pitch pin header circuit board connector Specifications: Product model: 2.54mm Pitch Pin Header- three rows of 180° single plastic Plastic height: 1.0 mm / 1.5 mm / 1.7 mm / 2.0 mm / 2.54 mm No.of circuits: 3*1P ~ 3*40P Material:Contact material: brass Direction of plating: gold plating on nickel base/tin plating on nickel base Plastic material: PBT,UL94V-0/PA6T,UL94V-0 Plastic color: black Electrical characteristics Rated current: 3.0AMP Contact resistance: 20 m Ω Max Insulation resistance: 5000 m Ω Min @ 500 v DC Resistant voltage: 1000V AC/1min Mechanical properties Contact size: 0.64mm SQ Operating temperature: -40°C ~ +105°C Welding temperature (PBT material) : 230+/-5℃, time: 5+/-0.5 SEC Welding temperature (PA6T material) : 260+/-5℃, time: 5+/-0.5 SEC Tin-dipping property (PBT material) : more than 90% of the tin-dipping area @ temperature: 230+/-5℃, time: 3+/-…
