2mm pitch pin header double row PCB connector

2mm pitch pin header double row PCB connector Specifications: Product model: 2.0mm Pitch Pin Header-H :4.0_ double row 90° Plastic height: 4.0mm No.of circuits: 2*2P ~ 2*40P Material: Contact material: brass Direction of plating: gold plating on nickel base/tin plating on nickel base Plastic material: PBT,UL94V-0/PA6T,UL94V-0 Plastic color: black Electrical characteristics Rated current: 2.0AMP Contact resistance: 20 m Ω Max Insulation resistance: 3000 m Ω Min @ 500 v DC Resistant voltage: 500V AC/1min Mechanical properties Contact size: 0.50mm SQ Operating temperature: -40°C ~ +105°C Welding temperature (PBT material) : 230+/-5℃, time: 5+/-0.5 SEC Welding temperature (PA6T material) : 260+/-5℃, time: 5+/-0.5 SEC Tin-dipping property (PBT material) : more than 90% of the tin-dipping area @ temperature: 230+/-5℃, time: 3+/-0.5 SEC Sin-dipping property (PA6T m…
